Fuel Oil – (Furnace Oil)
Specifications:
Fuel Oil is a fraction obtained from petroleum distillation, either as a distillate or a residue. Broadly speaking, oil is any liquid petroleum product, which is burned in a furnace or boiler for the generation of heat or used in an engine for the generation of power, except oils having a flash point of approximately 40 °C (104 °F). Oil is made of long hydrocarbon chains, particularly alkanes, cyclo alkanes and aromatics. The term Fuel Oil is also used in a stricter sense to refer only to the heaviest commercial fuel that can be obtained from crude oil, heavier than gasoline and naphtha. It is available in 125 Cst, 180 Cst and 380 Cst. grades.
Applications:
Fuel oils are used as fuel for power generation, marine bunkers and large industrial heating plants.
Packing:
Drum, Flexi & Bulk.
Data Sheet:
Fuel Oil 180 CST
Fuel Oil 380 CST
Fuel Oil 180 CST
| CHARACTERISTICS | UNIT | SPECIFICATION | TEST METHOD |
|---|---|---|---|
| Density at 15°C | kg/m3 | Max 991 | ISO 3675 or ISO 12185 |
| Kinematic Viscosity at 50°C | mm2 /S | Max 180 | ISO 3104 |
| Flash Point | °C | Min 60 | ISO 2719 |
| Pour Point (upper) (2) | |||
| Winter quality | °C | Max 30 | ISO 3016 |
| Summer quality | °C | Max 30 | ISO 3016 |
| Carbon residue | % (m/m) | Max 15 | ISO 10370 |
| Ash | % (m/m) | Max 0.10 | ISO 6245 |
| Water | % (V IV) | Max 0.50 | ISO 3733 |
| Sulphur | % (m/m) | Max 3.5 | ISO 8754 |
| Vanadium | mg/kg | Max 200 | IP 501/IP 470/ ISO 14579 |
| Aluminum Plus silicon | mg/kg | Max 80 | IP 501/IP470/ISO 10478 |
| Total sediment, potential | % (m/m) | Max 0.10 | ISO 10307-2 |
Fuel Oil 380 CST
| TEST | UNIT | SPECIFICATION | TEST METHOD |
|---|---|---|---|
| Density at 15°C | kg/m3 | Max 990 | D-1298 |
| Kinematic Viscosity at 50°C | CST | Max 380 | D-445 |
| Pour Point | DC | Min 32 | D-97 |
| Flash Point | °C | Min 65 | D-93 |
| Sulphur Total | wt % | Max 3.5 | ISO 3016 |
| Carbon residue (conradson) | wt % | Max 15 | ISO 3016 |
| Ash | wt % | Max 0.15 | ISO 10370 |
| Water and Sediment | Vol % | Max 1.0 | ISO 6245 |
| Calorific value (higher) | MJ/KG | Min 41.7 | ISO 3733 |
White Spirit
Mineral Spirits
Specifications:
Mineral spirits, also known as mineral turpentine, turpentine substitute, and petroleum spirits, is a petroleum-derived clear liquid used as a common organic solvent in painting.
Applications:
White spirit is used in paints, coatings, waxes, varnishes, adhesives, printing inks and liquid photocopier toners. In industry, it is also used as a solvent for, cleaning, degreasing and substance extraction.
Data Sheet:
Mineral Spirits
Mineral Spirits
| ANALYSIS | UNIT | TEST METHOD | LIMIT | |||
|---|---|---|---|---|---|---|
| Density@ 15 ºC | Kg/m3 | ASTM D1298 | 775 | |||
| Distillation | Cº | ASTM D86 | ||||
| IBP | 142-145 | |||||
| 10% | 148 | |||||
| 20% | 151 | |||||
| 30% | 154 | |||||
| 40% | 162 | |||||
| 50% | 166 | |||||
| 60% | 171 | |||||
| 70% | 176 | |||||
| 80% | 183 | |||||
| 90% | 191 | |||||
| 95% | 199 | |||||
| FBP | 226-230 | |||||
| RECOVERY | %VOL | ASTM D86 | 99.5 | |||
| Residue | 0.5 | |||||
| Loss | 0.5 | |||||
| Flash point | Cº | ASTM D92/93 | 39 min | |||
| Aromatic | %VOL | ASTM D5580 | 20 max | |||
| Total Sulfur | %Wt | ASTMD 4294 | 0.1 max | |||
| Benzene | %VOL | ASTM D5580 | <0.01 | |||
| Corrosion – 3 hrs @ 100 oC | - | ASTM D130 | 1:00 AM | |||
| Doctor Test | - | ASTM D4952 | Negative | |||
| Gum existent | Mg/100 Ml | ASTM D381 | 3 max | |||
| Neutrality | - | BS.245 | pass | |||
| Acidity of Residue | - | ASTM D1093 | pass | |||
Low Aromatic White Spirit
Specifications:
Low aromatic fuel is an unleaded petrol that has been designed to discourage people from sniffing by lowering the amount of the toxic aromatic components, which can cause intoxication. White spirit is made up of various liquid hydrocarbons, mainly aliphatic (paraffin) and also contain aromatic hydrocarbons (benzene, xylene).
Applications:
WLow Aromatic White Spirit is used as Solvent in thinner-paint and varnish. Solvent for paint. Solvent for producing polish for shoes, floor, and furniture. Solvent for chemical industry.
Packing:
Drum, Flexi & Bulk.
Data Sheet:
Low Aromatic White Spirit
Low Aromatic White Spirit
| Item | Test Method | Value |
|---|---|---|
| Density/Distillation | ASTM D 1298/D86 | 775 min |
| IBP | ASTM D 86 | 140 min |
| 10% | ASTM D 86 | 160 min |
| 50% | ASTM D 86 | 179 Max |
| 90% | ASTM D 86 | 194 Max |
| Dry Point | ASTM D 86 | 210 Max |
| FBP | ASTM D 86 | 220 Max |
| Residue | 1.5 Max | |
| Color | ASTM D 156 | + 28 |
| Flash Point | ASTM D 56 | 38 min |
| Corrosion | ASTM D 130 | 1a |
| Sulphur | ASTM D 1266 | 1000 ppm Max |
| Aromatic | ASTM D 1319 | 20 Max |
| Gum existent | ASTM D 381 | 5 Max |
| Dr test | ASTM D 4952 | Negative |
Base Oils
Specifications:
Base oils are used to manufacture products including lubricating greases, motor oil and metal processing fluids. Different products require different compositions and properties in the oil. One of the most important factors is the liquid’s viscosity at various temperatures. It is available in SN-150, SN-500, SN-650.
Applications:
Base oils are used to manufacture products including lubricating greases, motor oil and metal processing fluids.
Data Sheet:
Base Oil SN-150
Base Oil SN-500
Base Oil SN-650
Base Oil SN-150
| SPECIFICATION | UNIT | LIMITATION | TEST METHOD | ||
|---|---|---|---|---|---|
| MIN | TYP | MAX | |||
| APPEARANCE | -- | BRIGHT & CLEAR | VISUAL | ||
| COLOR | -- | -- | -- | 1.5 | ASTM D1500 |
| DENSITY | KG/M3 | -- | 880 | -- | ASTM D1298 |
| FLASH POINT(COC) | ^C | 205 | -- | -- | ASTM D92 |
| POUR POINT | ^C | -- | -- | -3 | ASTM D97 |
| VISCOSITY, KIN@100^C | CST | 5.0 | -- | -- | ASTM D445 |
| VISCOSITY INDEX | -- | 95 | -- | -- | ASTM D2270 |
Base Oil SN-500
| SPECIFICATION | UNIT | LIMITATION | TEST METHOD | ||
|---|---|---|---|---|---|
| MIN | TYP | MAX | |||
| APPEARANCE | -- | BRIGHT & CLEAR | VISUAL | ||
| COLOR | -- | -- | -- | 1.5-2.0 | ASTM D1500 |
| DENSITY | KG/M3 | -- | 885 | -- | ASTM D1298 |
| FLASH POINT(COC) | ^C | 235 | -- | -- | ASTM D92 |
| POUR POINT | ^C | -- | -- | -3 | ASTM D97 |
| VISCOSITY, KIN@100^C | CST | 11 | -- | -- | ASTM D445 |
| VISCOSITY INDEX | CST | 90 | -- | 95 | ASTM D2270 |
Base Oil SN-650
| SPECIFICATION | UNIT | LIMITATION | TEST METHOD | ||
|---|---|---|---|---|---|
| MIN | TYP | MAX | |||
| APPEARANCE | -- | BRIGHT & CLEAR | VISUAL | ||
| COLOR | -- | -- | 3 | -- | ASTM D1500 |
| DENSITY | KG/M3 | -- | 8978 | -- | ASTM D1298 |
| FLASH POINT(COC) | ^C | -- | 276 | -- | ASTM D92 |
| POUR POINT | ^C | -- | -6 | -- | ASTM D97 |
| VISCOSITY, KIN@100^C | CST | -- | 13.97 | -- | ASTM D445 |
| VISCOSITY INDEX | -- | -- | 86 | -- | ASTM D2270 |
Recycled Base Oil
Specifications:
Recycled Base Oil Used oil or waste oil is any type of mineral oil used in the production and industrial processes as lubricants or heat transmitter. During the operation, the oil reacts with oxygen and produces unsaturated polar compounds or asphalt.
Applications:
Recycled Base Oil is any type of mineral oil used in the production and industrial processes as lubricants or heat transmitter.
Packing:
Drum, Flexi & Bulk.
Data Sheet:
Recycled Base Oil
Recycled Base Oil
| No. | Properties | Value |
|---|---|---|
| 1 | COLOUR (ASTM) | 3 Max |
| 2 | DENSITY | 0.87-88 gm/cc |
| 3 | VISCOSITY, @40 0C | 70 Cst Min. |
| 4 | FLASH POINT(COC) | 2100C Min |
Light Diesel Oil
Specifications:
Light diesel oil, or LDO, is a blend of components from the distillation process of crude. It is used in engines with a rpm less than 750, such as boilers and furnaces. LDO is also referred to as distillate fuel or marked oil.
Applications:
LDO is a blend of distillates feed and residual oil. It is primarily recommended for stationary or slow speed diesel engines and as Industrial Fuel. LDO is used in medium and slow speed diesel engines with less than 750 rpm, typically.
Packing:
Drum, Flexi & Bulk.
Data Sheet:
Light Diesel Oil
Light Diesel Oil
Marine Fuel Oil
Specifications:
Marine fuel oil that has high calorific value to maximize marine propulsion. The marine fuel oil is produced taking into consideration viscosity grades required by ship engines of various dimensions. MFO of various viscosity grades.
MDO / MF-30 / MF-40 / MF-60 / MF-80 / MF-100 / MF-120 / MF-150 / MF-180 / MF-240 / MF-280 / MF-320 / MF-380 / MF-420 / MF-460. MFO is produced in accordance with the ISO 8217 standard
Applications:
Electricity generation, propulsion purposes powers road vehicles, earth-moving vehicles, forklifts and other commercial equipment.
Packing:
Tanker, Flexi & Bulk
Data Sheet:
Marine Fuel Oil
Marine Fuel Oil
Residual Fuel Oil
Specifications:
Residual fuel oil: A general classification for the heavier oils, known as No. 6 fuel oils, that remain after the distillate fuel oils and lighter hydrocarbons are distilled away in refinery operations.
Applications:
The primary end use for residual fuel oil is as a fuel in simple furnaces such as power plants and industrial boilers. It is also the primary fuel used on ocean-going ships, where it is called bunker fuel
Packing:
Drum, Flexi & Bulk.
Data Sheet:
Residual Fuel Oil
Residual Fuel Oil
Heavy End Oil
Specifications:
Heavy crude oil (or extra heavy crude oil) is highly-viscous oil that cannot easily flow from production wells under normal reservoir conditions. It is the highest boiling portion of a petroleum fraction.
Applications:
Heavy crude provide feedstock for plastics, petrochemicals, other fuels and road surfacing.
Packing:
Drum, Flexi & Bulk.
Data Sheet:
Heavy End Oil
Heavy End Oil
| PARAMETERS | METHOD | UNIT | RESULT |
|---|---|---|---|
| Appearance | Light Yellow | ||
| Color Saybolt | ASTM D 156 | 0.5 | |
| Density @15⁰C | ASTM D 1298 | kg/l | 0.805 |
| Flash Point | ASTM D 93 | °C | 60 |
| Viscosity@40°C | ASTM D 445 | cSt | 1.5 |
| DISTILLATION | |||
| IBP | ASTM D 86 | °C | 176 |
| FBP | ASTM D 86 | °C | 310 |
